Part Number Update

Bulletin No: PNU-161-000 Effective Date: June 23, 2011 Cancels: N/A Page: 1 of 2

Subject: Obsolescence Notice: Bendix

MC-30

™

ABS Modules, M-30T

™

Modulator Assemblies, and EC-30T

™

ABS ECUs with Power Line Carrier (PLC).

In light of the obsolescence of these parts, use the tables below to locate the replacement kit part number.

In cases where the current unit part number is not known:

• FindtheABSsystemcongurationusedonthetrailerbyusinghand-heldorPCdiagnostics(whereapplicable,

and where communication with the previous ECU is possible), or,

• Physically count the number of wheel speed sensors used on the trailer and check for a second modulator in use.

For Service Replacement of Bendix

MC-30

™

Trailer ABS Modules

Pigtail

Length

(S) 60"

(L) 234"

Bendix

TABS-6

™

Trailer ABS Module

Replacement Kits (including harnesses)

2S/1M

- Axle

2S/1M -

Dolly

2S/2M -

Side

4S/2M -

Side*

4S/2M -

Axle*

Part

Number

Description

800737

Bendix

MC-30

™

ABS Assembly

(TankMount)

Short 802893 802951 K060601 K060602 K061025

Long 802902 -- K061023 K061024 K061026

800820

Bendix

MC-30

™

ABS Assembly

(BracketMount)

Short 802893 802951 K060601 K060602 K061025

Long 802902 -- K061023 K061024 K061026

801033

Bendix

MC-30

™

ABS Assembly

(BracketMount)

Short -- 802951 -- -- --

5007643

Bendix

MC-30

™

ABS Assembly

(TankMount)

Short 802893 -- -- -- --

Long 802902 -- -- -- --

5007644

Bendix

MC-30

™

ABS Assembly

(TankMount)

Short -- -- -- K060602 --

Long -- -- -- K061024 --

5007646

Bendix

MC-30

™

ABS Assembly

(TankMount)

Short -- -- K060601 -- --

Long -- -- K061023 -- --

5008265

Bendix

MC-30

™

ABS Assembly

(BracketMount)

Short 802893 -- -- -- --

Long 802902 -- -- -- --

5008266

Bendix

MC-30

™

ABS Assembly

(BracketMount)

Short -- -- -- K060602 --

Long -- -- -- K061024 --

5008268

Bendix

MC-30

™

ABS Assembly

(BracketMount)

Short -- -- K060601 -- --

Long -- -- K061023 -- --

5008505 Bendix

MC-30

™

ABSAssembly(TankMount)

Short -- 802951 -- -- --

5008507

Bendix

MC-30

™

ABS Assembly

(TankMount)

Short -- -- -- K061025

Long -- -- -- -- K061026

5008536 Bendix

MC-30

™

ABSAssembly(Brkt.Mount)

Short -- 802951 -- -- --

5008538

Bendix

MC-30

™

ABS Assembly

(BracketMount)

Short -- -- -- -- K061025

Long -- -- -- -- K061026

5009157 Bendix

MC-30

™

ABSAssembly(Brkt.Mount)

Short -- 802951 -- -- --

For4S/2M(4sensor/2modulator)systems,todetermineiftheABSassemblyisusedtocontrolan“axle-control”

or“side-control”system,tracethedeliveryhosesfromoneofthemodulatorstoseeiftheactuatorscontrolledare

onthesamesideofthevehicle(a4S/2Msidesystem),oratbothendsofanaxle(4S/2Maxlesystem).

Note: Kits are described by

the number of sensors and

modulators

(e.g. 2S/1M is a

two sensor / one modulator

system)

1 2
